| MODEL NAME | 15 HP |
|---|---|
| MODEL NO. | AZAGC1501A |
| Grinding Capacity | 120 to 160 kg |
| Automation Grade | Semi Automatic |
| Material | MS Body |
| Power Source | Electric |
| Voltage (V) | 415 |
| Current (A) | 22 |
| Corrosion Resistance | Yes |
| Power Consumption | 14.00 KWH |
| Motor Speed | 2880 rpm |
| Frequency (HZ) | 50 |
| Motor Type | Three Phase |
| Coating | Powder Coating |
| Chamber | Double Chamber With Pedition |
| Machine Dimension Inch | L-65″ W-25″ H-53″ |
| Chamber Dimension Inch | 16″ Dia x 10.5″ Depth |
| Back Chamber Dimension Inch | 10″ Dia x 4″ Depth |
| Cyclone Motor | 0.5 hp & 1 hp |
| Cyclone Dimension Inch | L-22″ W-22″ H-83″ |
